Transmitters for ViscoScope Viscometer

  • Evaluation unit
  • Process viscometer
  • Transmitter for viscosity measurement
  • F-01-02-01

Transmitter VS-D250 and VS-4450

Transmitters compatible with ViscoScope

Marimex ®

Inline Viscometers – Our Passion

130
Max. Process temperature in °C
64
max. pressure in bar
65
Protection class according to IP rating
1000
Max. cable length in metres

Product advantages

  • factory calibrated and immediately ready for measurement.
  • Viscosity ranges covered over 4 decades
  • Analogue or serial transmission of the measurement data
  • compatible with all ViscoScope inline viscometers
  • Configurable display
  • Time-proportional control or alarms possible

Transmitter for viscosity sensors

Maximum flexibility for optimum choice of measuring instrument: The VS-D250 and VS-4450 transmitters are compatible with all ViscoScope® sensors of types VA-100 and VA-300. Viscosity ranges are covered by the internal resolution of 16 bits over four decades (e.g. 1 - 10,000 or 10 - 100,000 etc.). Even for measurements with very small viscosity difference (example: milk and whey) the transmitters work precisely. Both transmitters VS-4450 and VS-D250 are equipped with a freely configurable display. The transmission of measurement and diagnostic data to a process control system is done via industry standard analog or digital interfaces. The VS-4450 is optionally available with 2 SPDT relays for time proportional control or alarms. The VS-D250 model is designed for DIN rail mounting.

Images and technical drawings

Transmitter VS-D250

  • Housing: DIN rail mounting
  • Display: 2 x 4-line
VS-D250 Transmitter Viskosimeter

Transmitter VS-x450VS-x450 Transmitter

  • Mounting : wall or 19" rack
Transmitter VS-4450 Viskometer

dimensional drawing

Viskometer VA-300 technische Zeichnung

dimensional drawing

Viskometer VA-300 technische Zeichnung

Technical data

measurement parameters
Viscosity | Process temperature | Coil temperature | External input | Resonant frequency
Calculable parameters
Temperature Compensation | Dynamic Viscosity | Kinematic Viscosity | User viscosity
Display
4-line alphanumeric - 2 pages
outputs
front RS232 output | MODBUS RTU (standard)
Output card socket
4 (VS-4450) | 2 (VS-D250)
external input
0/4... 20 mA or 0/2... 10 VDC, e.g. for density or pressure
Transmitter controls
3 front buttons
filter
Moving average (up to 200 measured values)
Alarm
System function | Sensor diagnostics | Coil temperature | 2 adjustable LEDs
Power supply
95... 250 VAC, 50... 60 Hz, 15 W24 VAC / VDC (VVS-4450) | 24 VDC, 12 W (VS-D250)
dimensions
19" standard: 3HE 21TE x 180 mm | L x W x H142 x 106 x 73 mm
Housing
Panel enclosure 144 x 144 x 218 mm, IP42 | Wall enclosure, IP65 | 19" Rack, 3HE 84TE | Ex-d enclosure | DIN-rail housing, IP4
ambient temperature
0°C up to 50°C

Inline viscosity measurement in

  • Coatings
  • Paints and varnishes
  • Fine chemistry
  • Adhesives and sealants
  • Synthetic resins
  • Paper coatings
  • Polymers (PET, PE, PC, PA6, PIB, PS, PMMA and others))
  • Polymer melts (fibres, granulates)
  • Silicones
  • Suspensions, dispersions, emulsions
  • Black liquor
  • Cement

Documents and downloads

Data sheet VS-D250/VS4450

Download

general information

Download

Transmitter for inline viscosity measurement

The VS-D250 and VS-4450 transmitters are compatible with all ViscoScope® VA-100 and VA-300 sensors and their predecessors. This ensures the highest possible flexibility for optimal instrument selection and replacement of older transmitters. The internal resolution is 16 bits, providing excellent coverage of viscosity ranges over 4 decades (e.g. 1 - 10,000 or 10 - 100,000 etc.). The transmitters can also be set for measurements with very small viscosity difference (example: milk and whey). Both models are equipped with a freely configurable display. Transmission of measurement and diagnostic data to a process control system is via industry-standard analog or digital interfaces. VS-4450 is optionally available with 2 SPDT relays, which allow time proportional control or alarms. Constructed in 19" standard, the transmitter is delivered in a panel housing as standard. But other suitable housings, e.g. 19" rack, wall or Ex-d housings are also possible. The VS-D250 model is designed for DIN rail mounting. With an adapter, wall mounting as well as installation in a wall or Ex-d housing is possible.
